# Elasticsearch8+

ECE 认证工程师备考

# 安装

使用 Ubuntu16 系统

1
2
3
apt-get install elasticsearch
/etc/elasticsearch | /var/log/elasticsearch | /usr/share/elasticsearch
wget https://xxxx/elasticsearch.tar.gz
1
2
3
4
===================================================================================
elasticsearch.keystore 密文文件，不小心误删
===================================================================================
./bin/elasticsearch-keystore create
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
./elasticsearch-setup-passwords interactive

=====================================================================================
Failed to authenticate user 'elastic' against http://10.0.16.8:9200/_security/_authenticate?pretty
Possible causes include:
 * The password for the 'elastic' user has already been changed on this cluster
 * Your elasticsearch node is running against a different keystore
   This tool used the keystore at /home/ubuntu/elasticsearch-8.3.2/config/elasticsearch.keystore

You can use the `elasticsearch-reset-password` CLI tool to reset the password of the 'elastic' user
=====================================================================================

修改 elasticsearch.yml 的 xpack.security.enabled: false
删除 .security-7 索引
重新设置 xpack.security.enabled: true
1
2
3
4
5
6
7
===================================================================================
kibana.yml配置不支持使用elastic用户名，使用其他用户名
===================================================================================
比较合理的 elasticsearch-setup-password 脚本会设置 kibana_system 的用户和密码

elasticsearch.username: "kibana_system"
elasticsearch.password: "xxx"

# Data Management

# Define an index that satisfies a given set of requirements —— 定义一个满足条件的索引

  • analysis
  • setting
  • mapper

# Define and use an index template for a given pattern that satisfies a given set of requirements

1
2
3
4
5
6
7
8
9
10
11
PUT index-test
{
  "mappings": {
  	// 默认为true
    "date_detection": false
    // 设置时间格式
    "dynamic_date_formats": ["MM/dd/yyyy"]
    // 开启number类型检测，整数检测为long类型，浮点数检测为float类型
    "numeric_detection": true
  }
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
PUT test_index
{
  "mappings": {
    "dynamic_templates": [
      {
      	// 自定义名称
        "my_template": {
          // 匹配条件(match_mapping_type、match、unmatch、path:e.g 类似对象、path_unmatch)
          "match": "name*",
          "mapping": {
            "type": "keyword"
          }
        }
      }
    ]
  }
}

# Define and use a dynamic template that satisfies a given set of requirements

8 + 版本后 _template 逐渐被废弃，改为 _component_template 和 _index_template

1
2
3
4
5
6
7
PUT _index_template/my_template_name
{
	"template": {
		"mappings": {},
		"settings": {}
	}
}

# Define an Index Lifecycle Management policy for a time-series index

kibana： Stack Management >>> Index Lifecycle Management

# Define an index template that creates a new data stream

类似 ILM

need

  • a matching index template

  • a @timestamp field

原理：read all indices (now + back) /write now/newest index

索引格式： .ds-<data-stream>-<yyyy.MM.dd>-000001

add a new document： not use PUT /<target>/_doc/<_id> ，use PUT /<target>/_create/<_id>

# Use the Data Visualizer to upload a text file into Elasticsearch（不考）

kibana >>> machine learning >>> data visualizer

# Searching Data

# Write and execute a search query for terms and/or phrases in one or more fields of an index

match、term、match_phrase 的区别

  • match 查询会进行分词，匹配到单个即可
  • term 查询不会分词，必须完全匹配（适用 keyword 类型，类似 like）
  • match_phrase 查询会分词，必须完全匹配（适用 text 类型，类似 like）
# Boolean query
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
POST _search
{
  "query": {
    "bool" : {
      "must" : {
        "term" : { "field" : "value" }
      },
      "filter": {
        "term" : { "field" : "value" }
      },
      "must_not" : {
        "range" : {
          "age" : { "gte" : 10, "lte" : 20 }
        }
      },
      "should" : [
        { "term" : { "field1" : "value1" } },
        { "term" : { "field2" : "value2" } }
      ],
      "minimum_should_match" : 1,
      "boost" : 1.0
    }
  }
}

minimum_should_match 存在 should 时默认为 1，否则默认为 0

boost ：计算分数时使用

bool.filter ：不计算分数

_name ：每一个 top query 都可以添加，response 的 matched_queries 查看结果满足哪个 query。

# Boosting query & Constant score query
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
GET /_search
{
  "query": {
    "boosting": {
      "positive": {
        "term": {
          "text": "apple"
        }
      },
      // 匹配的document减negative_boost的分数
      "negative": {
        "term": {
          "text": "pie tart fruit crumble tree"
        }
      },
      "negative_boost": 0.5
    },
    "constant_score": {
      // 只有 filter 这一种
      "filter": {
        "term": { "user.id": "kimchy" }
      },
      // 匹配到数据分数指定为boost值
      "boost": 1.2
    }
  }
}
# Disjunction max query
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
GET /_search
{
  "query": {
    "dis_max": {
      // 满足多个 query 匹配的文档，根据 tie_breaker 增加分数
      // 0 <= tie_breaker <= 1
      "tie_breaker": 0.4,
      "boost": 1.2,
      "queries": [
        {"match":{}},
        {"match":{}},
        ...
      ]
    }
  }
}
# Intervals query

精确控制查询的 terms 顺序、terms 之间的距离以及包含关系的灵活控制

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
GET /_search
{
  "query": {
    "intervals": {
      "message": {
        "all_of": {
          // 按顺序匹配 xxxvalue1xxxvalue2xxx可以被查询到，xxxvalue2xxxvalue1xxx的文档不能配查询
          "ordered": true,
          // value1和value2的间距，0代表只能匹配xxxvalue1value2xxx的文档
          "max_gaps": 0,
          "intervals": [
            {
              "match": {
                "query": "value1"
              }
            },
            {
              "match": {
                "query": "value2"
              }
            }
          ]
        }
      }
    }
  }
}
# Match query

匹配 text、number、date or boolean value

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
GET _search
{
  "query": {
    "match": {
      "message": {
        "query": "cuury",
        // 模糊匹配 cuury 可以匹配到 curry
        "fuzziness": 1,
        // fuzzy前缀n位不更改
        "prefix_length": 2,
        // "a b" >>> or >>> a or b
        // "a b" >>> and >>> a and b
        "operator": "or/and"
      }
    }
  }
}
# Match boolean prefix
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
GET /_search
{
  "query": {
    "match_bool_prefix" : {
      "message" : "quick brown f"
    }
  }
}
等价于
GET /_search
{
  "query": {
    "bool" : {
      "should": [
        { "term": { "message": "quick" }},
        { "term": { "message": "brown" }},
        { "prefix": { "message": "f"}}
      ]
    }
  }
}
# match phrase query & match phrase prefix query
1
2
3
4
5
6
7
8
GET my-index-00002/_search
{
  "query": {
    "match_phrase": {
      "field": "value"
    }
  }
}
# Combined fields
1
2
3
4
5
6
7
8
9
10
11
12
GET _search
{
  "query": {
    "combined_fields": {
      "query": "quility.com Brogan Dante",
      // 查询 city 和 email 字段，^2代表匹配这个字段的boost=2
      "fields": ["city^2", "email"],
      // 默认为 or，or/and
      "operator": "or"
    }
  }
}

nested query

# Write and execute a search query that is a Boolean combination of multiple queries and filters

1
2
3
4
5
6
7
GET my-index-000001/_msearch
{}
{"query" : {"match_all" : {}}, "from" : 0, "size" : 10}
{}
{"query" : {"match_all" : {}}}
{"index" : "my-index-000002"}
{"query" : {"match_all" : {}}}

返回的 response 数组结果集，每个元素为一个查询结果

# search template

异步搜索

1
2
3
4
5
POST  my_index/_async_search
{
}

GET _sql/async/<id>

# Write and execute metric and bucket aggregations

  • 前置条件：【doc_values: true】

  • 不能用于 text 类型

  • 缓存，aggs 执行会将高频率的数据进行缓存，使用 "size":0 有效减少不必要的缓存，缓存适用于相同的 preference string

demo search aggs 如下

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
// typed_keys: 原本return name, 现在return type#name
GET my_index/_search?typed_keys
{
	"size": 0,	// 只返回 aggs 结果
	"aggs": {
		"my-first-agg-name": {
			"type (terms)": {
				"field": "my-field"
			},
			// 元数据：元数据也会带上这个field
			"meta": {
       	 		"my-metadata-field": "foo"
      		},
			// sub aggs
			"aggs": {
				"my-first-sub-agg-name": {
				}
			}
		},
		// 多个 aggs, 返回多个 result
		"my-second-agg-name": {
		}
	}
}

# metric aggs

计算指标：Max/Min、Average、Sum

不支持 sub-aggregations

  • Boxplot

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    "boxplot": {
      "field": "load_time"
    }

    // response
    "aggregations": {
      "load_time_boxplot": {
        "min": 0.0,
        "max": 990.0,
        // 第一个四分位数（前一半数据的中位数）
        "q1": 165.0,
        // 第二个四分位数（中位数）
        "q2": 445.0,
        // 第三个四分位数（后一半数据的中位数）
        "q3": 725.0,
    	"lower": 0.0,
        "upper": 990.0
      }
    }

# bucket aggs

支持 sub-aggregations

  • Adjacency matrix

    【向量】filter A B C -> return A B C A&B A&C B&C

  • Auto-interval date histogram

    自定义 buckets ，es 自动划分需要区间

    1
    2
    3
    4
    "auto_date_histogram": {
    	"field": "date",
        "buckets": 10
    }

  • Children

    适用于 join 类型

    1
    2
    3
    4
    5
    6
    7
    "aggs": {
      "join-aggs": {
        "children": {
          "type": "answer"
        }
      }
    }

  • Composite

    组合，合并多个 aggs 查询，source1：A1、A2，source2：B1、B2 -> A1B1、A1B2、A2B1、A2B2 的查询结果

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21
    22
    "aggs": {
        "my-aggs-name": {
          "composite": {
            "sources": [
              {
                "name01": {
                  "type": {
                    "field": "field-name"
                  }
                }
              },
              {
                "name02": {
                  "type": {
                    "field": "field-name"
                  }
                }
              }
            ]
          }
        }
      }

  • Histogram

    直方图 / 柱状图

    bucket_key = Math.floor((value - offset) / interval) * interval + offset

    1
    2
    3
    4
    5
    6
    7
    "histogram": {
      "field": "field-name",
      // 间隔
      "interval": 5,
      // 过滤 count < min_doc_count 的区间
      "min_doc_count": 1
    }

  • Date histogram

    date 作为 field type 的特殊 histogram

    bucket_key = Math.floor(value / interval) * interval

  • Range

    范围聚合查询，from <= value < to

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    "aggs": {
      "price_ranges": {
        "range": {
          "keyed": true,
          // 可以查询script field
          "field": "price",
          "ranges": [
            // 可以没有to，也可以没有from
            { "to": 100.0 },
            // 范围可以重叠
            { "from": 80.0, "to": 200.0 },
            { "from": 200.0 }
          ]
        }
      }
    }

  • Date range

  • Global

    定义一个单独包含全部数据的 bucket，使得当前聚合不受 query 查询的影响（全部数据作为聚合目标）

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    POST /sales/_search?size=0
    {
      "query": {
        "match": { "type": "t-shirt" }
      },
      "aggs": {
        // 全部商品平均价格（match_all）
        "all_products": {
          "global": {},
          "aggs": {
          "avg_price": { "avg": { "field": "price" } }
          }
        },
        //  t-shirt商品平均价格（query有关）
        "t_shirts": { "avg": { "field": "price" } }
      }
    }

  • Missing

    缺少字段或者字段值为 null 的 document 缺少 bucket ，通过 missing 聚合统计

    1
    2
    3
    4
    5
    "aggs": {
      "products_without_a_price": {
        "missing": { "field": "price" }
      }
    }

  • IP prefix 和 IP range

    IP 地址相关的聚合，xxx.xxx.xxx.xxx

  • Random sampler

    随机取样聚合，0 < probability < 0.5 || probability = 1

    随机取集合 * probability 的集合，每次结果可能不相同

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    {
      "aggregations": {
        "sampling": {
          "random_sampler": {
            "probability": 0.1
          },
          "aggs": {
            "price_percentiles": {
              "percentiles": {
                "field": "taxful_total_price"
              }
            }
          }
        }
      }
    }

# pipeline aggs

# Other

配置 elasticsearch.yml

1
2
transport.host: xxx.xxx.xxx.xxx
transport.port: 9300

证书问题

1）使用相同的 CA 证书：复制 ca.crt 和 ca.key

2）使用不同证书

# 创建集群远程连接

Stack Management >>> Remote Clusters

或通过 Dev Tools 实现

1
2
3
4
5
6
7
8
9
10
11
12
13

PUT _cluster/settings
{
  "persistent": {
    "cluster.remote": {
      "remote_cluster": {
        "seeds": [
          "192.168.0.8:9300"
        ]
      }
    }
  }
}
# 配置跨集群复制

Stack Management >>> Cross Cluster Replication

参数 说明
Remote cluster 添加的集群名称
Leader index 待迁移的索引。
Follower index 迁移数据生成的索引。索引名称不可重复。
